DF-2010    - Wide Angle

DF-2010C  - Constant Curtain

DF-2010PI - Pet Immunity 45Kg

In outdoor environments, false alarms are a common nuisance that can lead to unnecessary panic or resource waste. However, this detector, armed with its advanced DFIR™ technology, effectively discriminates between genuine human movement and other interfering factors (such as animals, wind-blown foliage, temperature fluctuations, etc.), thereby significantly reducing false alarm rates.

Furthermore, the detector boasts an array of additional strengths, including high sensitivity, a wide detection range, and robust anti-interference capabilities. These features collectively position it as a leader in outdoor security monitoring. Whether for home security, commercial surveillance, or any other high-security application, this detector reliably provides accurate alarm services, safeguarding users' safety.

• IP65 Waterproof Housing


• Dual Frequency Infrared ( DFIR^TM ) opto-electronic system - Six element infrared detector

• Dual Frequency Infrared technology ( DFIR^TM ) for superior pet-immune motion-sensing.Up to 45Kgs Pet Immunity ( DF-2010PI )

• SureTrac^TM Constant-Width Curtain Detection Pattern ( DF-2010C )


• World-class immunity to shock, white light, temperature, RF, electrical surges

• Wide Range Operating Temperature ( -40°C to +55°C )

• Adjustable sensitivity for different requirements

• Look-down detection directly below the sensor, to catch wall-creeping intruders

• Three Stage White Light Protection


DF-2010 | DF-2010C | DF-2010PI Installation Manual : Click here

0-ML00-3140-01-1（DF-2010）Manual.pdf
